Dimensions (mm) length * width * height
1300012500 * 2500 * 3400360038004000
Carriage inner dimensions (mm) length * width * height
12850127851235012285 * 232023502380 * 600
Axis number
Three
The wheelbase (mm)
6880 1310 13106480 1310 1310
Number of spring steel
-/10/10/10, -/4/4/4
Tire specifications
11R22.5 12PR, 11.00R20 12PR, 12R22.5 12PR
Tire number
Twelve
Tread front / rear (mm)
- / 1840/1840/1840
The total mass (kg)
Forty thousand
Rated load (kg)
Three billion three hundred million thirty-three thousand and five hundred
The quality of service (kg)
Seventy million six thousand and five hundred
Semi-trailer maximum allowable bearing quality (kg)
Sixteen thousand
Approach / departure angle (DEG)
-/13, -/13
Front / rear suspension (mm)
-/2200, -/2100
The axle load (kg):
-/24000 (and three axis)
The vehicle identification code (VIN):
LMC940C3 x x x x x x x x x
other
The container floor height to the top of the warehouse gate for 1800mm, 2000mm, 2200mm, 2400mm and the overall height are corresponding; the back door optional flower column type structure, the open semi closed structure, the full closed structure; optional side to open the door and flower bar style; gate with vertical corrugated, square Guan Pingban, square cross flower style; the optional side door style column; optional interpolation, extrapolation style; the front baffle is corrugated structure, the shape of long 13000mm and 12500mm corresponding to the container inside length were 12850mm and 12350mm; car shape 13000mm long wheelbase 6680 1310 1310mm is optional, the rear suspension is 2400mm, departure angle of 13 degrees; mass changes caused by the optional less than 3% manufacturers; ABS system for Guangzhou Comet automobile brake technology development Co. Ltd., type CM2XL-4S/2M; protective device material made of Q235 steel, the connection for the welding, the rear protective device section The size of 160mm * 80mm, height 500mm
