Dimensions (mm) length * width * 130001250012000 * 2500 * 29002700
Carriage inner dimensions (mm) length * width * height * 238023502320 * 600 128501278512350122851185011785
Axis number 3
The wheelbase (mm 6880 1310 13106680 1310 13106480 1310 13106280 1310 1310)
Number of spring steel -/10/10/10, -/8/8/8
11.00R20 12PR 12R22.5 12PR tire specifications.
Tire number 12
Tread front / rear (mm) - / 1840/1840/1840
The total mass (kg) 38000
Rated load (kg) 31700
The quality of service (kg) 6300
Semi-trailer maximum allowable bearing quality (kg) 14200
Approach / departure angle (degrees) -/13, -/12, -/13, -/16
Front / rear suspension (mm) -/2200, -/2300, -/2100, -/1800
The axle load (kg): -/23800 (and three axis)
The vehicle identification code (VIN): LMC938B3 x x x x x x x x x
Anti lock braking system:
Reflective logo enterprise: Changzhou huarsheng reflective material Co., Ltd., 3M Chinese Co. Ltd., Changzhou Huawei reflective material Co Ltd
Trademarks: transparent card, 3M, April Les
ID type: TM1200-1983D, HW1400
Other: corresponding to the vehicle shape long 13000mm wheelbase respectively 6880 1310 13106680 1310 1310; side tailgate optional 5 open fan or 6 fan; tailgate optional flatbed, Bouvardia or corrugated structure; column optional in or in; optional rear style, side railing like type and block style can be any combination; ABS system manufacturer for Guangzhou comet vehicle brake technology development Co., Ltd., model CM2XL-4S/2M; protection device material with Q235 steel plate, connection mode: the side door and the frame are connected by a bolt, door and frame is welded, section dimensions of the rear guard of 160mm * 80mm, ground height is 500mm
